Phosphorus Bronze Rod

We are one of the leading Phosphor Bronze Rod manufacturers in India. We manufacture these Phosphor Bronze Rods at our well-equipped production unit.

Our Phosphor Bronze Rods are durable, immune to extreme weather and usage. We offer these rods in different specifications depending upon the buyer’s requirements.

We are productive enough to handle all individual and bulk orders for phosphorus bronze rod in a limited period and we ensure timely delivery as well. Phosphor Bronze Rods we offer is widely used and applauded by the maximum number of users in the market. The phosphor bronze rods provided by us are highly demanded by the clients, owing to their reliable performance and longer working life.

Our phosphor bronze rods are manufactured using high-grade material which is obtained from trusted vendors.

Reputed Phosphorus Bronze Rod Exporter

We offer these phosphor bronze rods at a very competitive price. Phosphor bronze products, offered by us, have no rough surfaces that provide greater flexibility for installation. Phosphor bronze rods have excellent spring qualities, high fatigue resistance, good formability and solderability, and high corrosion resistance. Our manufactured phosphor bronze rod assures performance, efficiency, and durability.

Phosphor bronze is used for springs, bolts, and various other items used in situations where resistance to fatigue, wear, and chemical corrosion is required.The inclusion of tin increases the resistance to corrosion and strength of the material, phosphor increases the wear resistance and hardness. Thus phosphorus bronze is used in numerous electrical and industrial applications, based on its varying Tin content.

We offer Phosphorus Bronze Rods which are widely appreciated by the clients in the national and international markets. These rods are used for diverse applications in different industries such as in heavy engineering, defence, aviation, electrical, and more. These rods exhibit features like preventing galvanic corrosion, particularly by insulating steel screws from aluminum surfaces. Our main attribute is quality and we make sure that all our manufactured products comply with the international standards. Our quality auditor carries out numerous quality tests to inspects the products and to ensure that they meet all requirements and standards before shipping out the range for the final shipment.

When it comes to delivery, we make sure that all the arrangements are done for punctual and safe deliveries.

Product Gallery

Applications

Automobiles
Washers
Electrical connectors
  • House Hold Repair
  • Fasteners
  • Switch parts
  • Electronic & precision equipment parts
  • Welding rods
  • Springs
  • Bushings
  • Pinions

Features

  • High strength
  • Precise dimensions
  • Resistance against corrosion
  • Excellent Quality
  • Fine Finishing
  • High Strength

MANUFACTURING PROCESS

ALLOY SPECIFICATIONS CHEMICAL COMPOSITIOM MECHANICAL PROPERTIES
BS ASTM EN IS ( % AVERAGE) (AVERAGE)
CU SN P ZN PB FE TENSILE STRENGTH, Mpa YIELD STRENGTH, Mpa % elongation
PHOSPHOROUS BRONZE 95/5 PB 102 C 51000 CW491K IS 7811 BAL. 4.2/5.8 0.01/0.30 0.3 0.02 0.1 450 380 10
92/8 CuSn8 C52100 CW 453K X BAL. 7.5/8.5 0.01/0.40 0.2 0.02 0.1 450 280 15
90/10 PB1 C52400 CC 480 X BAL. 9.5/11.0 0.2 0.2 0.05 0.1 510 170 10
88/12 PB2 X CC484K X BAL. 11.2/13.0 0.6 0.5 1 0.2 330 120 8
GUN METAL
LG-2 C 83600 C 491K IS 10742 BAL. 4.0/6.0 0.01/0.30 4.0/6.0 4.0/6.0 0.2 380 200 8
LG-4 C93200 CC 493K IS 10742 BAL. 6.0/8.0 0.02 1.7/3.7 2.7/4.0 0.2 300 130 6
LEADED BRONZE
LB-2 C 93700 CC 495K IS 320/LTB-3 BAL. 9.0/11.0 0.05/0.12 2 9.0/10.50 0.25 280 125 6
LB-1 C 93800 CC 496K IS 320/LTB-4 BAL. 6.0/8.0 0.1 NI-0.5/2.0 13/17 0.2 250 125 6

SIZE RANGE

ALLOY SPECIFICATIONS SIZES
BS ASTM EN IS ROUND HEX/SDQUARE RECTANGULAR* HOLLOW *
PHOSPHOROUS BRONZE 95/5 PB 102 C 51000 CW491K IS 7811 4 TO 70 MM CAST AND DRAWN, UP TO 400 MM AS CAST 8 TO 80 MM CAST AND DRAWM, 81 TO 100 MM AS CAST 10 MM TO 130 MM WIDTH, ABOVE 5 MM THICKNESS OD 10 MM TO 80 MM WITH 3 MM WALL THICKNESS MIN CAST AND DRAWN, ABOVE 80 TO 125 MM AS CAST
92/8 CuSn8 C52100 CW 453K X 4 TO 70 MM CAST AND DRAWN, UP TO 400 MM AS CAST 8 TO 80 MM CAST AND DRAWM, 81 TO 100 MM AS CAST 10 MM TO 130 MM WIDTH, ABOVE 5 MM THICKNESS OD 10 MM TO 80 MM WITH 3 MM WALL THICKNESS MIN CAST AND DRAWN, ABOVE 80 TO 125 MM AS CAST
90/10 PB1 C52400 CC 480 X 12 MM TO 400 MM AS CAST 12 MM TO 100 MM AS CAST 10 MM TO 130 MM WIDTH, ABOVE 5 MM THICKNESS OD 10 MM TO 125 MM WITH WALL THICKNESS 10 MM MIN AS CAST
88/12 PB2 X CC484K X 12 MM TO 400 MM AS CAST 12 MM TO 100 MM AS CAST 10 MM TO 130 MM WIDTH, ABOVE 5 MM THICKNESS OD 10 MM TO 125 MM WITH WALL THICKNESS 10 MM MIN AS CAST
GUN METAL
LG-2 C 83600 C 491K IS 10742 4 TO 70 MM CAST AND DRAWN, UP TO 400 MM AS CAAST 8 MM TO 80 MM CAST AND DRAWN, 81 TO 100 MM AS CAST 10 MM TO 130 MM WIDTH, ABOVE 5 MM THICKNESS OD 10 MM TO 125 MM WITH WALL THICKNESS 10 MM AS CAST
LG-4 C93200 CC 493K IS 10742 4 TO 70 MM CAST AND DRAWN, UP TO 400 MM AS CAAST 8 MM TO 80 MM CAST AND DRAWN, 81 TO 100 MM AS CAST 10 MM TO 130 MM WIDTH, ABOVE 5 MM THICKNESS OD 10 MM TO 125 MM WITH WALL THICKNESS 10 MM AS CAST
LEADED BRONZE
LB-2 C 93700 CC 495K IS 320/LTB-3 12 MM TO 400 MM AS CAST 12 MM TO 100 MM AS CAST NA OD 10 MM TO 125 MM WITH MINIMUM WALL THICKNESS 10 MM AS CAST
LB-1 C 93800 CC 496K IS 320/LTB-4 12 MM TO 100 MM AS CAST NA OD 10 MM TO 125 MM WITH MINIMUM WALL THICKNESS 10 MM AS CASAT
